Allen-Bradley Push Button Station 800S-2SD4 600V AC Max

The Allen-Bradley 800S-2SD4 is a Standard Duty push button operator station from the 800S Series, configured with Raise and Lower legend plates for motor reversing, hoist, conveyor, and crane control applications. Catalog number 800S-2SD4 designates a two operator pre-assembled station in a NEMA Type 4 watertight metal enclosure, suitable for indoor and outdoor industrial environments where protection against splashing water and hose directed water is required. The unit features momentary contact push button operators with Raise and Lower legends, designed for direct wiring into motor starter control circuits. Each operator typically provides one normally open and one normally closed contact rated for standard duty pilot duty service per NEMA A600 contact rating. The 800S Series is commonly applied in material handling, overhead crane pendant control, hoist control, valve actuation, and reversing motor starter installations. Construction includes a corrosion resistant metal enclosure with mounting feet, conduit entry provisions, and a hinged or screw secured cover. Rated for 600 volts AC maximum operating voltage. The 800S-2SD4 is part of the legacy Allen-Bradley Bulletin 800S product family and is used as a direct replacement or spare for existing installations specifying this catalog number. Specifications listed are sourced from Rockwell Automation published 800S Series documentation. Buyers should verify catalog number, contact configuration, and enclosure rating match the intended replacement application.

Stock # 0526-02335
