Square D Heavy Duty Safety Switch H361NDS 600 V
Square D Heavy Duty Safety Switch H361NDS 600 V
Couldn't load pickup availability
- U.S. shipping, securely packaged. Ships in 1-2 Days
- Questions? Real support team available before purchase
- Secure checkout with trusted payment methods
Condition:
Photos reflect the item’s current condition and details. If the item arrives in a condition that differs from what is shown or described, it may be eligible for return or refund. Please review our product condition guide prior to purchasing.
MPN: H361NDS
Stock #: 0526-02321
The Square D H361NDS is a heavy duty fusible safety switch rated for 30 amps at 600 volts AC/DC, configured with three poles and a factory installed neutral. The enclosure is constructed from 304 stainless steel and carries a NEMA 3, 3R, 4, 4X, 5, and 12 rating, making it watertight, dust tight, and corrosion resistant for both indoor and outdoor installations. Horsepower rating is 20 HP maximum at 600 volts. Equipment terminals are suitable for either aluminum or copper conductors. The switch is part number 15221741, Series F06, with UPC 785901025726, and is supplied in original Square D by Schneider Electric factory packaging. Fuses are not included with the unit, and the switch is configured to accept H, K, and R fuse types as shipped, with field modification available for J fuses. The H361NDS is rated for 50/60 Hz operation and includes the quick make, quick break operating mechanism, dual cover interlock, and color coded indicator handle that are standard across the Square D F Series heavy duty safety switch line. Typical applications include service entrance disconnects when equipped with a neutral assembly or equipment grounding kit, motor disconnects, and main or branch circuit disconnects in industrial, commercial, food processing, water treatment, and outdoor installations where corrosion resistance is required. Surface mounting configuration. Net product weight is listed at 14.0 lbs per the carton label.
Stock # 0526-02321
