Angular Clamping Device Heavy-Duty Cast Iron Right Angle Plate | 59 1/2 H x 30 1/2 W x 30 1/2 L

This heavy-duty cast iron right angle plate features a webbed open-back construction with two cast horizontal ribs providing structural rigidity under machining loads. The vertical face is equipped with a uniform grid of drilled and tapped holes for versatile clamping and fixture point placement. Additional drilled holes are present along the base and side faces for securing the unit to a machine table, rotary table, or floor plate. A forged lift ring is mounted to the top center for overhead crane handling. A clamp or stop bolt assembly is installed on the vertical face. The casting shows a red oxide primer finish consistent with traditional machine tool workholding equipment. No manufacturer nameplate is present. Estimated dimensions are 59 1/2 H x 30 1/2 W x 30 1/2 L, with an estimated weight in the range of 700 to 900 lbs based on cast iron construction and visible wall thickness. Cast iron right angle plates of this type are commonly used as vertical clamping surfaces on horizontal boring mills, jig borers, and large vertical machining centers, and as 90-degree reference fixtures in heavy fabrication and assembly applications. The open webbed back reduces weight while maintaining face rigidity.

Stock # 0226-294
