Square D Heavy Duty Safety Switch VH362NAWKGL 600V

The Square D VH362NAWKGL is a VisiPacT heavy duty fusible safety switch rated for 60 amps at 600 VAC and 600 VDC. This three pole disconnect features a factory installed solid neutral and equipment ground lugs, making it suitable for service entrance applications when paired with the appropriate kit. The Type 12 (NEMA 12) galvannealed steel enclosure protects against dust, falling dirt, and dripping noncorrosive liquids in indoor industrial environments. A factory installed viewing window allows visual confirmation of the switch state with the cover closed. The VisiPacT series incorporates a quick make, quick break operating mechanism, a dual cover interlock that prevents opening the cover while the switch is on, and a color coded indicator handle showing red for ON and black for OFF. The unit accepts Class H, K, and R fuses as shipped and can be field modified to accept Class J fuses. Short circuit rating is 10 kA or up to 200 kA depending on the fuses installed. The switch supports motor loads up to 50 HP at 600 VAC three phase. Wire range accommodates AWG 12 through AWG 3 aluminum and AWG 14 through AWG 3 copper conductors. Surface mounted configuration with single throw operation. UL listed under file E2875 and E154828, tested per UL98 and NEMA KS1 standards. New in box, factory sealed Schneider Electric packaging. Reference codes 15244371 and GEX47695 visible on the carton label.

Stock # 0526-02269
